HORIZONTAL LEAD BLOCKS
Stock No. |
WLL
(tons) |
Wire size
up to(mm) |
Bearing |
Dimensions (mm) |
Weight
(kgs)
|
D1 |
D2 |
A |
B |
C |
F |
G |
H |
T |
R |
TA |
TB |
TC |
25.125.01.70 |
1 |
10 |
Bronze |
125 |
105 |
180 |
150 |
22.5 |
27 |
22 |
9 |
8 |
5.5 |
200 |
170 |
54 |
5 |
25.150.02.70 |
2 |
12 |
Bronze |
150 |
120 |
220 |
190 |
31 |
40 |
30 |
11 |
10 |
6.5 |
250 |
220 |
72 |
10 |
25.200.03.70 |
3 |
14 |
Bronze |
200 |
165 |
290 |
240 |
33 |
40 |
30 |
13.5 |
12 |
7.5 |
320 |
270 |
76 |
17 |
25.250.04.70 |
4 |
18 |
Bronze |
250 |
210 |
360 |
310 |
38.5 |
45 |
35 |
17.5 |
15 |
9.5 |
400 |
350 |
86 |
32 |
25.300.06.70 |
6 |
20 |
Bronze |
300 |
255 |
400 |
360 |
46 |
50 |
40 |
22 |
20 |
11 |
450 |
410 |
99 |
50 |
25.350.08.70 |
8 |
22 |
Bronze |
350 |
305 |
460 |
420 |
46 |
50 |
45 |
26 |
20 |
12 |
520 |
480 |
99 |
70 |
25.400.10.70 |
10 |
24 |
Bronze |
400 |
345 |
530 |
480 |
51 |
60 |
50 |
32 |
20 |
13 |
600 |
550 |
113 |
100 |
Minimum Ultimate Strength = 4 x WLL.
Stock No. |
WLL
(tons) |
Wire size
up to (mm) |
Bearing |
Dimensions (mm) |
Weight
(kgs) |
D1 |
D2 |
A |
B |
C |
F |
G |
H |
T |
R |
TA |
TB |
TC |
25.125.01.71 |
1 |
10 |
2 x Ball |
125 |
105 |
180 |
150 |
22.5 |
27 |
22 |
9 |
8 |
5.5 |
200 |
170 |
54 |
5 |
25.150.02.71 |
2 |
12 |
2 x Ball |
150 |
120 |
220 |
190 |
31 |
40 |
30 |
11 |
10 |
6.5 |
250 |
220 |
72 |
10 |
25.200.03.71 |
3 |
14 |
2 x Ball |
200 |
165 |
290 |
240 |
33 |
40 |
30 |
13.5 |
12 |
7.5 |
320 |
270 |
76 |
17 |
25.250.04.71 |
4 |
18 |
Straight |
250 |
210 |
360 |
310 |
38.5 |
45 |
35 |
17.5 |
15 |
9.5 |
400 |
350 |
86 |
32 |
25.300.06.71 |
6 |
20 |
Straight |
300 |
255 |
400 |
360 |
46 |
50 |
40 |
22 |
20 |
11 |
450 |
410 |
99 |
50 |
25.350.08.71 |
8 |
22 |
Straight |
350 |
305 |
460 |
420 |
46 |
50 |
45 |
26 |
20 |
12 |
520 |
480 |
99 |
70 |
25.400.10.71 |
10 |
24 |
Straight |
400 |
345 |
530 |
480 |
51 |
60 |
50 |
32 |
20 |
13 |
600 |
550 |
113 |
100 |
Minimum Ultimate Strength = 4 x WLL.
WLL= Working Load Limit.
Grooves can be adapted to other wire sizes.
No test certificate possible.
|
